P-511 Conductivity Meter
2018-7-12
Measure
conductivity, TDS, salinity and resistivity of water solutions, suitable for
industrial and mining factories, water treatment engineering and environmental
protection, especially for outdoor use.
Main Features:
●Large
LCD screen with controllable white backlight.
●Built-in
microprocessor chip with functions of auto calibration, auto temperature
compensation, data storage, function setup, self-diagnosis, auto power off, low
voltage display.
●Auto
recognition of 8 standard conductivity solutions and there are two series of
standard buffers for option: USA series, China series.
●Adopt advanced conductivity measurement technology, one point calibration
of conductivity electrode can meet the measuring accuracy requirements for test
0.5μ S/cm ~ 200mS/cm.
●Able to switch between conductivity, TDS, salinity and resistivity.
Multinomial calculation for TDS and salinity to ensure the conversion precision
of the full scale.
●Conductivity mode has the function of non-linear temperature compensation
for high purity water.
●Humanized
designs like rack and skid proof shell make it more convenient for users.
●
Plastic conductivity electrode with automatic
temperature compensation to ensure fast and accurate result.
●
Grade IP57 and provide optional carrying case.
Specifications
|
Conductivity |
Measuring range |
Conductivity: (0.00~19.99) μS/cm (20.0~199.9) μS/cm (200~1999) μS/cm (2.00~19.99) mS/cm (20.0~199.9) mS/cm TDS: (0 ~ 100) g/L Salinity: (0~100) ppt Resistivity: (0 ~ 100）MΩ·cm |
|
Resolution |
0.01/0.1/1μS/cm 0.01/0.1 mS/cm |
|
|
Accuracy |
Electrode: ±1.0% FS Instrument: ±1.5%FS |
|
|
Temperature compensation |
(0~100)℃(automatic) |
|
|
Electrode constants |
0.1/1/10 cm-1 |
|
|
Reference temperature |
25℃, 20℃,18℃ |
|
|
Others |
Data storage |
200 sets |
|
Storage contents |
Series number, measuring value, measuring unit and temperature |
|
|
Power |
Two AA batteries(1.5V) |
|
|
Size & Weight |
160×90×30mm/360g (instrument) 480×300×60mm/1KG (with packing) |
|
|
Working Conditions |
Ambient temperature |
(5~35)℃ |
|
Ambient humidity |
≤85% |
|
|
IP grade |
IP57 |
Standard Configuration
1. P-511 Conductivity meter 1 unit
2. Conductivity electrode 1 pc
3. Backup AA battery 2 pcs
5. Operation manual 1 copy
