L-511 Conductivity Meter
2018-7-12
Main Features:
1. 5 inch LCD screen with wide 150° viewing angle, beautiful and compact design.
2. Compact bench cradle with rotary electrode holder to save space in laboratory.
3. Small size and portable make it easy to carry and remove in laboratory and outdoors.
4. Extendibility: different electrodes can be installed to test pH, conductivity and dissolved oxygen.
5. Auto recognition of different electrodes after electrode is connected.
6. 3.5 mm jack input for electrodes makes it very easy for electrode connection.
7. Two USB one SD card interfaces for power and data transfer.
8. Can store 300 pieces of data including readings, date and time.
9. Rechargeable and long lasting battery. Auto shut off if there is no operation in ten minutes.
Specifications
|
Conductivity |
Measuring range
Resolution Accuracy Temp compensation range Electrode constant |
Conductivity: (0.00 ~ 20.00) μS/cm (20.0 ~ 200.0) μS/cm (200 ~ 2000) μS/cm (2.00 ~ 20.00) mS/cm (20.0 ~ 200.0) mS/cm Resistivity: (0 ~ 100) MΩ·cm TDS: (0 ~ 100) g/L Salinity: (0 ~ 100) ppt 0.01/0.1/1μS/cm 0.01/0.1mS/cm Electrode: ±1.0% FS, Instrument: ±1.50%FS (0 ~ 100)℃ (Automatic) 0.1/1/10 cm-1 |
|
Temperature |
Measuring range Resolution Accuracy |
0 ~ 100℃ 0.1℃ 5 ~ 60℃: ±0.5℃, Others: ±1.0℃ |
|
Other parameters |
Data storage Power Communication connectors Dimensions & Weight |
200 sets DC 5V/1A Micro USB and standard USB 190*130*18mm/0.31KG |
|
Working conditions |
Ambient temperature Ambient humidity IP grade |
(5 ~ 35)℃ ≤85% IP54 |
Standard Configurations
1. L-511 conductivity meter 1 unit
2. Conductivity electrode 1 pc
3. Electrode holder 1 pc
4. 5V/1A power adapter 1 pc
5. Instruction manual 1 copy
